AES EPIC 1D - M04 PUMP 1; AUTOTUNING; CHANGE MINIMUM AMPERAGE; CHANGE MAXIMUM AMPERAGE

1716
EPIC 1DEPIC 1D
Installation Installation
M04 PUMP 1
AUTOTUNING
AUTOSET: P1
XXXV XXA 09S
M04 PUMP 1
>AUTOTUNING
>EXIT
M04 PUMP 1
>AUTOTUNING
>AUTOTUNING
ON
AUTOTUNING
>ON
CHANGE NOMINAL CURRENT
NOM. CURRENT
>XXX.X
M04 PUMP 1
>NOM. CURRENT
>EXIT
M04 PUMP 1
>NOM. CURRENT
>NOM. CURRENT
000.1
NOM. CURRENT
>000.0
ACCESS TO FUNCTION MODIFIED PARAMETERS
>M04 PUMP 1
M06 PROGRAM
The amperage value shown on the display may differ
± 5% from the nominal value of the pump (nameplate
data) since the control panel is not a measuring
instrument. The same value may differ depending on
the operating conditions of the installation.
AUTOTUNING
It allows the self-learning of the data to be carried out again
NOMINAL CURRENT
Set nominal/operating current of the pump
MINIMUM AMPERAGE
Current setting min. for dry running protection
MAXIMUM AMPERAGE
Max current setting for overcurrent protection
START PER HOUR
Set max number of pump starts per hour
CHANGE MINIMUM AMPERAGE
MIN AMPERAGE
>XXX %
M04 PUMP 1
>MIN AMPERAGE
>EXIT
M04 PUMP 1
>MIN AMPERAGE
>MIN AMPERAGE
085 %
MIN AMPERAGE
>085 %
CHANGE MAXIMUM AMPERAGE
MAX AMPERAGE
>XXX %
M04 PUMP 1
>MAX AMPERAGE
>EXIT
M04 PUMP 1
>MAX AMPERAGE
>MAX AMPERAGE
130 %
MAX AMPERAGE
>130 %
CHANGE START PER HOUR
START PER HOUR
>XX
M04 PUMP 1
>START PER HOUR
>EXIT
M04 PUMP 1
>START PER HOUR
>START PER HOUR
06
START PER HOUR
>06
