9.2 Fuse replacement
DANGER
Risk of death by electric shock!
► Unplug the device before changing the fuses!
Specified fuse set: 2 units IEC 127 – T 6.3 A switching capacity H (1 500 A
at 250 V/50 Hz)
► Use a small screwdriver to release the clip on the fuse holder 12.
► Pull out the fuse holder 12.
► Replace both fuses.
► Reinsert the fuse holder 12 in such a way that it audibly snaps into
place.
Note
If the fuses regularly blow, the unit is defective and has to be repaired. see
Chapter 10.
10. Technical Service
DANGER
Danger to life of patients and users in case of malfunctions and/or
failure of protective measures!
► Do not perform any servicing or maintenance work under any cir-
cumstances while the product is being used on a patient.
CAUTION
Modifications to medical equipment may result in loss of guaran-
tee/warranty claims and any approvals.
► Do not modify the product.
► For service and repairs, please contact your national
B. Braun/Aesculap representative.
Modifikationen an medizintechnischer Ausrüstung können zu einem Ver-
lust der Garantie-/Gewährleistungsansprüche sowie eventueller Zulassun-
gen führen.
► Für Service und Instandsetzung wenden Sie sich an Ihre nationale
B. Braun/Aesculap-Vertretung.
Service addresses
Aesculap Technischer Service
Am Aesculap-Platz
78532 Tuttlingen / Germany
Phone: +49 (7461) 95 -1601
Fax: +49 (7461) 14 -939
E-Mail: ats@aesculap.de
Or in the US:
Aesculap Inc.
Attn. Aesculap Technical Services
615 Lambert Pointe Drive
Hazelwood
MO, 63042 USA
Aesculap Repair Hotline
Phone: +1 (800) 214 -3392
Fax: +1 (314) 895 -4420
Other service addresses can be obtained from the address indicated above.
11. Accessories/Spare parts
11.1 ELAN 4 electro motor cables, applied parts and
foot controls
Art. no. Designation
GA804 ELAN 4 electro motor cable with hand lever
(from software version 2.00)
GA805 ELAN 4 electro motor cable with hand control
(from software version 2.00)
GA806 ELAN 4 electro motor cable for foot control
GA808 ELAN 4 electro foot control
GA810 ELAN 4 electro wireless foot control (from soft-
ware version 3.00)
GA822 ELAN 4 electro perforator driver
GA824 ELAN 4 electro Lowspeed motor with intra cou-
pling
GA831 ELAN 4 electro sagittal saw
GA832 ELAN 4 electro reciprocating saw
GA833 ELAN 4 electro transverse saw
GA836 ELAN 4 electro micro sagittal saw
GA837 ELAN 4 electro micro reciprocating saw
GA844 ELAN 4 electro drill tool (from software version
3.00)
GA849 ELAN 4 electro craniotome and multifunctional
handpiece (2-ring)
GA860 ELAN 4 electro MIS hand piece
GA861 ELAN 4 electro Standard handpiece (1-ring) L4
GA862 ELAN 4 electro Standard handpiece (1-ring) L7
GA863 ELAN 4 electro Standard handpiece (1-ring) L10
GA864 ELAN 4 electro Standard handpiece (1-ring) L13
GA865 ELAN 4 electro Standard handpiece (2-ring) L7
GA866 ELAN 4 electro Standard handpiece (2-ring) L10
GA867 ELAN 4 electro Standard handpiece (2-ring) L13
GA868 ELAN 4 electro Standard handpiece (2-ring) L17
GA869 ELAN 4 electro Standard handpiece (2-ring) L22
SOP-AIC-
5001568
(TA014401)
Instructions for use of ELAN 4 electro control unit
GA800
Document No.: IFU - Version: 3.0 - Document ID: SOP-AIC-5001568 Date/Time Printed/Viewed: 2022-04-13 15:59 (CET)
