3
USA
Applied part types Display/control elements in the applied part
control panel
Display/control elements in the pump control
panel
Symbol Text Art. no. Designation
Perforator GA822 ELAN 4 electro perforator
driver
Intra GA824 ELAN 4 electro Lowspeed
motor with intra coupling
Saw GA831 ELAN 4 electro sagittal
saw
GA832 ELAN 4 electro reciprocat-
ing saw
GA833 ELAN 4 electro transverse
saw
GA836 ELAN 4 electro micro sag-
ittal saw
GA837 ELAN 4 electro micro
reciprocating saw
Highspeed GA849 ELAN 4 electro cranio-
tome and multifunctional
handpiece (2-ring)
GA860 ELAN 4 electro MIS
hand piece
GA861 ELAN 4 electro Standard
handpiece (1-ring) L4
GA862 ELAN 4 electro Standard
handpiece (1-ring) L7
GA863 ELAN 4 electro Standard
handpiece (1-ring) L10
GA864 ELAN 4 electro Standard
handpiece (1-ring) L13
GA865 ELAN 4 electro Standard
handpiece (2-ring) L7
GA866 ELAN 4 electro Standard
handpiece (2-ring) L10
GA867 ELAN 4 electro Standard
handpiece (2-ring) L13
GA868 ELAN 4 electro Standard
handpiece (2-ring) L17
GA869 ELAN 4 electro Standard
handpiece (2-ring) L22
Drill GA844 ELAN 4 electro power drill
Symbol Designation
Activation mode of motor via foot control GA808
Activation of motor via wireless foot control GA810
Activation of motor via hand control
GA804/GA805/GA844
Motor direction indicator for clockwise rotation pre-
selected
The display depends on whether the motor is acti-
vated or disabled.
Motor direction indicator for counterclockwise rota-
tion preselected
The display depends on whether the motor is acti-
vated or disabled.
Reduce the maximum speed setting
Increase the maximum speed setting
Symbol Designation
Identification of the control panel for the coolant
and irrigation pump
Display in active applied part control panel
Switch on the pump
Switch off the pump
Activate the “Flush” function (continuous flushing)
Reduce the delivery rate
Increase the delivery rate
Document No.: IFU - Version: 3.0 - Document ID: SOP-AIC-5001568 Date/Time Printed/Viewed: 2022-04-13 15:59 (CET)
