AET T6 - Rail Installation; Bolt U-Bracket and Rail Together

7 pages

To Next Page

To Previous Page

3.'Assembly'9'ConXnued'

2)'Rail'InstallaXon'

Place'rail'in'U9Bracket'opening'and'rest'the'rail'

on'the'U9Bracket'bolt.'

3)'Bolt'U9Bracket'and'Rail'together.'

Using'a''1/2”'socket'with'ratchet'or'driver,'

torque'the'U9Bracket'bolt'to'25'in/lb.'Ensure'

the'top'inward'facing'tabs'on'both'sides'of'the'

U9Bracket'Assembly'are'above'the'side'chan nel'

of'the'rail.'
