10
in.k600™
Gasket with or without
adhesive
To install the in.k600™ low profile, use the drilling template
provided in this section. Determine the mounting location and
stick the template on chosen location. The user must cut out a
rectangular shape opening of 7.250" by 3.750" according to the
template (see illustration).
Clean the installation surface and peel the adhesive gasket from the
back of the keypad.
Insert keypad and align it correctly, then ensure it's properly glued
by gently pressing evenly on the entire surface.
Installation in.k600™ low profile
Optional
wing nuts and
spacers
installation
7.250"
3.750"
