9
TOOLS REQUIRED:
F 8 mm L-Wrench
F 13/17 mm Flat Wrench
F 5 mm L-Wrench/Screwdriver
F Screwdriver (not included)
PARTS INCLUDED:
F 1 Main Frame
F 1 Stabilizer Tube
F 1 Guide Rail Set
F 1 Console Mast
F 2 Pedal Arms
F 2 Lower Handlebars
F 2 Upper Handlebars
F 2 Handlebar Cover Sets
F 2 Lower Link Arms With Footpads
F 1 Front Top Cap Piece
F 1 Rear Top Cap Piece
F 1 Console
F 1 Audio Adapter Cable
F 1 Power Cord
F 1 Hardware Kit
UNPACKING
Unpack the product where you will be using it. Place the elliptical carton on a
level flat surface. It is recommended that you place a protective covering on
your floor. Never open box when it is on its side.
If you have questions or if there are any missing parts, contact Customer
Tech Support. Contact information is located on the back panel of this
manual.
NEED HELP?
PRE ASSEMBLY
• It is recommended that two people work together for ease and efficiency
while assembling an elliptical.
• During each assembly step, ensure that ALL nuts and bolts are in
place and partially threaded. It is recommended you complete the full
assembly of your unit before completely tightening any ONE bolt.
• Several parts have been pre-lubricated to aid in assembly and usage.
Please do not wipe this off. If you have difficulty, a light application of
lithium bike grease is recommended.
IMPORTANT NOTES
