ASSEMBLY STEP 5
A Open HARDWARE FOR STEP 5.
B Align SUPPORT BAR (7) on top of CONSOLE
MASTS (1 & 4).
C Attach the SUPPORT BAR (7) to the
CONSOLE MASTS (1 & 4) using 4 BOLTS (D).
HARDWARE FOR STEP 5
PART TYPE DESCRIPTION QTY
D BUTTON HEAD BOLT M6X1.0PX15L 4
ASSEMBLY COMPLETE!
Before the first use, lubricate the treadmill deck by
following the instructions in the MAINTENANCE
section in the TREADMILL GUIDE.
