AFi MB-DB-HML - Page 5

Page 5 of 9
STEP 6
STEP 7
QUEEN
Adult assembly
03
Guide the back panel (03) in carefully so that it won’t jump out of its grooves. Be sure
it fits fully into its groove at the . Install wood dowels (A) as shown
below.
top panel base
Guide the (04) in carefully so that it won’t jump out of its grooves.middle back rail
Using JCB (D) and barrel nut (E). Tighten with Allen wrench ( ).M
04
04
E
E
A
A
A
A
E
D
D
JCB M6 X mm60
Barrel Nut
Allen wrench
D
E
M
Adult assembly
Wooden dowel
A
MURPHY BED
WITH CHARGING STATION
