AFi MB-DB-HML - Page 8

Page 8 of 9
H
H
I
I
STEP 12
STEP 13
Attach triangle metal bracket (H) to the back of cabinet as shown below. Use wood
screw (I) tighten with Phillips head screwdriver. (customer supplied).
Triangle metal bracket
Wood Screw 1”
H
I
Adult assembly
QUEEN
Pull the drawer out fully. Unlatch the door and open, folding down as shown.
Open
Adult assembly
MURPHY BED
WITH CHARGING STATION
