DETECTED SITUATION
ERROR DISPLAYED ON
DISPLAY
POSSIBLE REASON
SOLUTION
USER
TECHNICAL SOLUTION
Red triangle Door 2 open alarm Close the second door Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Check: input D2, door sen-
sor.
Compressor not working The compressor is not
working
Opening of power line Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Reset circuit breaker
Red triangle and machine
in lock mode
Electrical power alarm Check the electrical power
supply voltage.
Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Compare network voltage
with machine rating plate
Red triangle Alarm: food probe not
inserted !
Needle probe test failed Correctly insert the probe
Red triangle Preservation alarm The preservation cycle is
about to end.
Remove the product from
the temperature regulator
and stop the cycle. After
defrost is complete, you
may resume standard use
of the machine
Red triangle Low temperature alarm HACCP signals air tem-
perature too low compared
to set value.
Check programmed param-
eters
Check that air probe and
evaporator are working
properly
Red triangle High temperature alarm HACCP signals air tem-
perature too high compared
to set value.
Check programmed param-
eters
Check that air probe and
evaporator are working
properly
Red triangle Air probe (S1) alarm Cell probe damaged/broken Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Replace probe S1
Red triangle Evaporator probe (S2)
alarm
Evaporator probe dam-
aged/broken
Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Replace probe S2
Red triangle Condenser probe (S3)
alarm
Condenser probe Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Replace probe S3
Red triangle and machine
in lock mode
Overheating probe alarm
(SAUX)
Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Check: overhating probe,
SAUX input. Replace probe
if necessary !
Red triangle Food probe (PT1) alarm Check: food probe, PT1
input. Replace probe if
necessary !
Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Replace needle probe
Red triangle Food probe (PT2) alarm Check: food probe, PT2
input. Replace probe if
necessary !
Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Replace needle probe
Red triangle Food probe (PT3) alarm Check: food probe, PT3
input. Replace probe if
necessary !
Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Replace needle probe
Red triangle Food probe (PT4) alarm Check: food probe, PT4
input. Replace probe if
necessary !
Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Replace needle probe
Red triangle Pressure probe alarm
(RH%)
Call a qualifi ed engineer
and inform him of the read
error and product serial
number
Check: pressure probe,
RH% input Replace probe if
necessary !
