Connect the Smart Meter to Three-phase System
13
Step 3
Step 2
Note:
After activate "PQD"
function, please
restart the inverter.
UP/DOWN
Choose SET
UP/DOWN Choose
Communication
SET
ESC
UP/DOWN Choose ON
and press ENT to confirm
UP/DOWN
Choose PQD
UP/DOWN selection
password:6231
UP/DOWN Choose Meter
press ENT to confirm
ENT
Para Adj
UP/DOWN Choose
COM2 Protocol
Communciate Para View
COM1 Address: 01
COM1 Protocol RS485
COM2 Address: 01
COM2 Protocol ModBus
UP/DOWN
Choose Running
1s Delay1s Delay1s Delay 1s Delay
ENT
Enter User Password
ENT
SET
System
Running
Protection
Communication
Running Adj
PQD: ON
PQ mode: OFF
Power Percent: xx%
Main Menu
Run Info
Err Record
SET
ON/OFF
Wifi Info
Version
System Info
System Checking...
>>>>>>>>
ww.aforenergy.com
Power
xx KW
xx KWh
xx KWh
Run
110
50
0
5 8
11 14 1720 23
t
P(%)
28/8/2020 11:00
EDay
EAll
State
xxxx
Running
PQD: OFF
PQ mode: OFF
Power Percent: xx%
ENT
ENT
ENT
ENT
System
Running
Protection
Communication
Address: 01
Protocol: Meter
Baud rate 9600
