Connect the Smart Meter to Single-phase System

4. Connect the Smart Meter to Single-phase System

4.1 System Diagram

PV GENERATOR

Afore Simplex

SAPM-10KW Meter

HOUSEHOLD CONSUMERS

GRID

Communication path

Power path

......

RS485

HNS1000TL-1~HNS10000TL

Inverter

LOAD

L N

RS485B

RS485A

LINE

DDSU666 DIN-RAIL METER

230V */100mA 800imp/kWh

(White)

3 4

(Blue)

Note:

When the load exceeds 10kW, a CT needs to be added, see the

figure below:
