BARCOB2: 10 DMX channel mode:
Channel Value Function Description
CH1 0~255 Master dimmer Dimmer
CH2
0~9 No function
10~249 Strobe Strobe（From slow to fast）
250~255 No function
CH3 0~255 Red dimmer lens 1 Red
CH4 0~255 Green dimmer lens 1 Green
CH5 0~255 Blue dimmer lens 1 Blue
CH6 0~255 Red dimmer lens 2 Red
CH7 0~255 Green dimmer lens 2 Green
CH8 0~255 Blue dimmer lens 2 Blue
CH9
0~9 No function
10~119 Operating mode Auto program
120~255 Sound program
CH10 0~255 Auto program speed Speed for auto program（From slow to fast）
BARCOB4: 16 DMX channel mode:
Channel Value Function Description
CH1 0~255 Master dimmer Dimmer
CH2
0~9 No function
10~249 Strobe Strobe（From slow to fast）
250~255 No function
CH3 0~255 Red dimmer lens 1 Red
CH4 0~255 Green dimmer lens 1 Green
CH5 0~255 Blue dimmer lens 1 Blue
CH6 0~255 Red dimmer lens 2 Red
CH7 0~255 Green dimmer lens 2 Green
CH8 0~255 Blue dimmer lens 2 Blue
CH9 0~255 Red dimmer lens 3 Red
CH10 0~255 Green dimmer lens 3 Green
CH11 0~255 Blue dimmer lens 3 Blue
CH12 0~255 Red dimmer lens 4 Red
CH13 0~255 Green dimmer lens 4 Green
CH14 0~255 Blue dimmer lens 4 Blue
CH15
0~9 No function
10~119 Operating mode Auto program
120~255 Sound program
CH16 0~255 Auto program speed Speed for auto program（From slow to fast）
© Copyright LOTRONIC 2015 BARCOB2 / BARCOB4 Page 5
