EN 22
© Copyright LOTRONIC 2019
DMX Channel Tables:
DMX MODE1:3 CH
CH1 0-255 ALL RED (0-100%)
CH2 0-255 ALL GREEN (0-100%)
CH3 0-255 ALL BLUE (0-100%)
DMX MODE2:5 CH
CH1 0-255 Dimmer (Master dimmer)
CH2
0-9 No Function
Strobe (Strobe)
10-255 Slow->Fast
CH3 0-255 ALL RED (0-100%)
CH4 0-255 ALL GREEN (0-100%)
CH5 0-255 ALL BLUE (0-100%)
DMX MODE3:8 CH
CH1 0-255 Dimmer (Master dimmer )
CH2 0-255 ALL RED (0-100%)
CH3 0-255 ALL GREEN (0-100%)
CH4 0-255 ALL BLUE (0-100%)
CH5 (When CH6 value <10, this DMX
Channels is valid)
0-9 No Function (CH2-Ch4 eective)
10-13 Static color(CH7 Choice)
14-17 Built-in eects 1
18-21 Built-in eects 2
22-25 Built-in eects 3
26-29 Built-in eects 4
30-33 Built-in eects 5
34-37 Built-in eects 6
38-41 Built-in eects 7
42-45 Built-in eects 8
46-49 Built-in eects 9
50-53 Built-in eects 10
54-57 Built-in eects 11
58-61 Built-in eects 12
62-65 Built-in eects 13
66-69 Built-in eects 14
70-73 Built-in eects 15
74-77 Built-in eects 16
78-81 Built-in eects 17
82-85 Built-in eects 18
86-89 Built-in eects19
90-93 Built-in eects20
94-97 Built-in eects 21
98-101 Built-in eects 22
102-105 Built-in eects 23
106-109 Built-in eects 24
110-113 Built-in eects 25
114-117 Built-in eects 26
To Next Page
