afx light BARLED200-FX User Manual

EN5
www.afx-light.com
MENU STRUCTURE
Mode Programming Description
Auto mode Auto Auto mode
DMX mode Addr
3 CH A001-A510
Each DMX Channel mode has
its individual address.
Connect a controller and the
unit will enter into DMX mode.
5 CH A001-A508
8 CH A001-A505
24CH A001-A489
48CH A001-A465
53CH A001-A460
Show Shou
Sh 1-54 Program Show 1-54 (54 built-in effects)
Sp 1-10 Program Speed 1-10 (slow->fast) (Speed)
St 0-9 Program Flash 0-9 (slow->fast) (Strobe)
Sound Mode Soud
Sou1
Sen1-9
Mic Sensitivity (Sound mode,
sensitivity adjustable)
Sou2
Sou3
Edit color Colo
r000-255 Red (0-100%) Red adjustment
g000-255 Green (0-100%) Green adjustment
b000-255 Blue (0-100%) Blue adjustment
St 0 – St 9 LED Strobe (slow->fast) (Strobe)
Static colors StAt
CL00-
CL26
RGB static color (Static color)
Slave SLAV Slave Slave (Slave mode, Automatic identication slave unit)
Information Info ver VVxx Soft version
Product Set Set
dis
10s
Set backlight time of display
board,
10 S to light up
The factory default is 10 S
20s
30
60s
on
dir
---> Set the direction to the right
<--- Set the direction to the left
DMX Channel Tables see at the end of the manual
SPECIFICATIONS
Power supply .................................................................................................................... 110-240V~50/60Hz
Consumption ................................................................................................................................................60W
Total max. power at the POWER OUT output ...................................................................................... 1500W
LED .................................................................................................................. 8 x 28pcs SMD5050 RGB 3-in-1
Dimensions .................................................................................................................................. 101 x 6 x 6cm
Weight ......................................................................................................................................................... 1.6kg
IMPORTANT NOTE: Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local
authorities or your dealer about the way to proceed.

afx light BARLED200-FX Specifications

General

Brand	afx light
Model	BARLED200-FX
Category	Lighting Equipment
Language	English
