afx light BARLED200-FX User Manual

EN 24
© Copyright LOTRONIC 2019
64-69
Segment 10 LED light up, CH2, CH3, CH4 control color
(CH7>100, the other LED segments are o󰊞)
70-75
Segment 11 LED light up, CH2, CH3, CH4 control color
(CH7>100, the other LED segments are o󰊞)
76-81
Segment 12 LED light up, CH2, CH3, CH4 control color
(CH7>100, the other LED segments are o󰊞)
82-87
Segment 13 LED light up, CH2, CH3, CH4 control color
(CH7>100, the other LED segments are o󰊞)
88-93
Segment 14 LED light up, CH2, CH3, CH4 control color
(CH7>100, the other LED segments are o󰊞)
94-99
Segment 15 LED light up, CH2, CH3, CH4 control color
(CH7>100, the other LED segments are o󰊞)
100-105
Segment 16 LED light up, CH2, CH3, CH4 control color
(CH7>100, the other LED segments are o󰊞)
CH6
106-111 Pattern E󰊞ect 1(CH2, CH3, CH4 Control pattern color)
112-117 Pattern E󰊞ect 2(CH2, CH3, CH4 Control pattern color)
118-123 Pattern E󰊞ect 3(CH2, CH3, CH4 Control pattern color)
124-129 Pattern E󰊞ect 4(CH2, CH3, CH4 Control pattern color)
130-135 Pattern E󰊞ect 5(CH2, CH3, CH4 Control pattern color)
136-141 Pattern E󰊞ect 6(CH2, CH3, CH4 Control pattern color)
142-147 Pattern E󰊞ect 7(CH2, CH3, CH4 Control pattern color)
148-153 Pattern E󰊞ect 8(CH2, CH3, CH4 Control pattern color)
154-159 Pattern E󰊞ect 9(CH2, CH3, CH4 Control pattern color)
160-165 Pattern E󰊞ect 10(CH2, CH3, CH4 Control pattern color)
166-171 Pattern E󰊞ect 11(CH2, CH3, CH4 Control pattern color)
172-177 Pattern E󰊞ect 12(CH2, CH3, CH4 Control pattern color)
178-183 Pattern E󰊞ect 13(CH2, CH3, CH4 Control pattern color)
184-189 Pattern E󰊞ect 14(CH2, CH3, CH4 Control pattern color)
190-195 Pattern E󰊞ect 15(CH2, CH3, CH4 Control pattern color)
196-201 Pattern E󰊞ect 16(CH2, CH3, CH4 Control pattern color)
202-207 Pattern E󰊞ect 17(CH2, CH3, CH4 Control pattern color)
208-213 Pattern E󰊞ect 18(CH2, CH3, CH4 Control pattern color)
214-219 Pattern E󰊞ect 19(CH2, CH3, CH4 Control pattern color)
220-225 Pattern E󰊞ect 20(CH2, CH3, CH4 Control pattern color)
226-231 Pattern E󰊞ect 21(CH2, CH3, CH4 Control pattern color)
232-237 Pattern E󰊞ect 22(CH2, CH3, CH4 Control pattern color)
238-243 Pattern E󰊞ect 23(CH2, CH3, CH4 Control pattern color)
244-255 Pattern E󰊞ect 24(CH2, CH3, CH4 Control pattern color)
CH7
0-255 DMX Program Speed (Slow->fast)
0-9 No function
10-19 Static color 1 (10<=CH5 Value <=13)
20-29 Static color 2 (10<=CH5 Value <=13)
30-39 Static color 3 (10<=CH5 Value <=13)
40-49 Static color 4 (10<=CH5 Value <=13)
50-59 Static color 5 (10<=CH5 Value <=13)
60-69 Static color 6 (10<=CH5 Value <=13)
70-79 Static color 7 (10<=CH5 Value <=13)
80-89 Static color 8 (10<=CH5 Value <=13)
90-99 Static color 9 (10<=CH5 Value <=13)
100-109 Static color 10 (10<=CH5 Value <=13)
110-119 Static color 11 (10<=CH5 Value <=13)
