afx light BARLED200-FX User Manual

EN 28
© Copyright LOTRONIC 2019
220-229 Static color 22 (10<=CH5 Value<=13)
230-239 Static color 23 (10<=CH5 Value<=13)
240-249 Static color 24 (10<=CH5 Value<=13)
250-255 Static color 25 (10<=CH5 Value<=13)
CH8
0-9 No Function
Strobe (Strobe)
10-255 Slow->Fast
CH9 0-255 Segment 1 LED dimmer
When CH6<10 &
CH5<10,This dmx control
verse 1 LED brightness,
CH2~CH3 control color
CH9 0-255 Segment 2 LED dimmer
... ... ...
CH23 0-255 Segment 15 LED dimmer
CH24 0-255 Segment 16 LED dimmer
DMX MODE5: 48CH
CH1 0-255 RED1 (0-100%)
CH2 0-255 GREEN1 (0-100%)
CH3 0-255 BLUE1 (0-100%)
CH4 0-255 RED2 (0-100%)
CH5 0-255 GREEN2 (0-100%)
CH6 0-255 BLUE2 (0-100%)
--- --- ---
CH46 0-255 RED16 (0-100%)
CH47 0-255 GREEN16 (0-100%)
CH48 0-255 BLUE16 (0-100%)
DMX MODE6: 53CH
CH1 0-255 Dimmer(Master Dimmer )
CH2 0-255 RED1 (0-100%)
CH3 0-255 GREEN1 (0-100%)
CH4 0-255 BLUE1 (0-100%)
CH5 0-255 RED2 (0-100%)
CH6 0-255 GREEN2 (0-100%)
CH7 0-255 BLUE2 (0-100%)
, , , , , , , , ,
CH47 0-255 RED16 (0-100%)
CH48 0-255 GREEN16 (0-100%)
CH49 0-255 BLUE16 (0-100%)
CH50 (when CH51 value <10, this DMX chan-
nel is valid)
0-9 No Function (CH2-Ch49 Valid)
10-13 Static color(CH52 Choose)
14-17 Built-in e󰊞ects 1
18-21 Built-in e󰊞ects2
22-25 Built-in e󰊞ects 3
26-29 Built-in e󰊞ects 4
30-33 Built-in e󰊞ects 5
34-37 Built-in e󰊞ects 6
38-41 Built-in e󰊞ects 7
42-45 Built-in e󰊞ects 8
46-49 Built-in e󰊞ects 9
