afx light CHASER-MOVING-BAR - DMX Channel Charts

EN 2
© Copyright LOTRONIC 2024
DMX CHANNEL TABLE
CH7 CHANNEL CHART
CH CH Value Basic function
1 000-255 Y-axis motor
2 000-255 Y-axis motor speed
3 000-255 Linear dimming of red lamp beads.
4 000-255 Linear dimming of green lamp beads.
5 000-255 Linear dimming of blue lamp beads.
6 000-255 Linear dimming of white lamp beads.
7 000-255 Reset: When the parameter value is 150-255, the whole machine is reset. The
parameter value of the console must be pulled below 10 rst, and then pushed to
150-255 to be useful. The parameter value of 000-149 is useless and cannot be
reset.
CH13 CHANNEL CHART
CH CH Value Basic function
1 000-255 Y-axis motor
2 000-255 Y-axis motor speed
3 000-255 Total dimming
4 000-255 Strobe
5 000-255 Linear dimming of red lamp beads.
6 000-255 Linear dimming of green lamp beads.
7 000-255 Linear dimming of blue lamp beads.
8 000-255 Linear dimming of white lamp beads.
9 000-255 Mode
10 000-255 Speed
11 000-255 background color
12 000-255 background color dimming
13 000-255 Reset: When the parameter value is 150-255, the whole machine is reset. The
parameter value of the console must be pulled below 10 rst, and then pushed to
150-255 to be useful. The parameter value of 000-149 is useless and cannot be
reset.
