DMX CHANNEL CHARTS
4 CHANNELS
CH Channel value Description
1 000-255 Red bead linear dimming
2 000-255 Green bulb linear dimming
3 000-255 Blue bead linear dimming
4 000-255 White bulb linear dimming
11 CHANNELS
CH Channel value Description
1 000-255 Total dimming
2 000-255 Three in one stroboscopic
3 000-255 Three in the rst mock exam (see: six, mode effect)
4 000-255 Three in the rst mock exam speed
5 000-255 Red bead linear dimming
6 000-255 Green bulb linear dimming
7 000-255 Blue bead linear dimming
8 000-255 White stroboscopic
9 000-255 White light mode (see VI. mode effect for details)
10 000-255 White light mode speed
11 000-255 White light bulb linear dimming
32 CHANNELS
CH Channel value Description
1 000-255 Section 1 three in one red light bead linear dimming
2 000-255 Section 1 three in one green light bead linear dimming
3 000-255 Section 1 three in one blue light bead linear dimming
4 000-255 Section 2 three in one red light bead linear dimming
5 000-255 Section 2 three in one green light bead linear dimming
6 000-255 Section 2 three in one blue light bead linear dimming
…
22 000-255 Section 8 three in one red light bead linear dimming
23 000-255 Section 8 three in one green light bead linear dimming
24 000-255 Segment 8 three in one blue light bead linear dimming
25 000-255 Section 1 white light bulb linear dimming
26 000-255 Linear dimming of section 2 white light bulb
27 000-255 Section 3 white light bulb linear dimming
28 000-255 Section 4 white light bulb linear dimming
29 000-255 Section 5 white light bulb linear dimming
30 000-255 Section 6 white light bulb linear dimming
31 000-255 Section 7 white light bulb linear dimming
32 000-255 Section 8 white light bulb linear dimming
