EN7
www.afx-light.com
8. REFRESH RATE ( TO SET THE PWM REFRESH RATE OF LED)
This device has optional LED PWM refresh rates for professional camera reqirements.
Press MENU to Select Refresh Rate mode, press ENTER, then use UP and DOWN to select the fol-
lowing refresh modes:
Refresh [ 800 HZ ]
Refresh [ 2000 HZ ]
Refresh [ 4000 HZ ]
Refresh [ 10 KHZ ]
Refresh [ 20 KHZ ]
Refresh [ 25 KHZ ]
9. KEYS LOCK (KEYS LOCK/UNLOCK PASSWORD)
Press MENU to select the Keys Lock, press ENTER. Then use UP and DOWN to set the keys lock
function to Lock [ No ] or [ Yes ].
When select Lock [ Yes ], the keys will be locked after 30 seconds without operating.
Input password UP+DOWN+UP+DOWN, press ENTER to unlock the keys.
When select Lock [ No ], the key lock function is not available.
DMX VALUES
This device has 5 DMX modes: 12CH (Tour), 6CH, 8CH, HSV & HSI
12 CH (TOUR) MODE
Channel DMX Value Function
1 000 - 255 Master Dimmer
2 000 - 255 Red 0 - 100%
3 000 - 255 Green 0 - 100%
4 000 - 255 Blue 0 - 100%
5 000 - 255 White 0 - 100%
6 000 - 255 Amber 0 - 100%
7 000 - 255 Purple (UV) 0 – 100%
8
000 - 009 No function
010 - 255 Strobe (1-20Hz)
9
Color Macros & White Balance
000 - 010 No function
011 - 030 Red 100%, Green 0%~100%, Blue 0%
031 - 050 Red 100%~0%, Green 100%, Blue 0%
051 - 070 Red 0%, Green 100%, Blue 0%-100%
071 - 090 Red 0%, Green 100%~0%, Blue 100%
091 - 110 Red 0%~100%, Green 0%, Blue 100%
111 - 130 Red 100%, Green 0%, Blue 100%~0%
131 - 150 Red 100%, Green 0%~100%, Blue 0%~100%
151 - 170 Red 100%~0%, Green 100%~0%, Blue 100%
171 - 200 Red 100%, Green 100%, Blue 100%, White 100%
201 - 205 White 1
206 - 210 White 2
211 - 215 White 3
216 - 220 White 4
