EN9
www.afx-light.com
145 – 149 Gobo 13 shake (from slow to fast)
150 – 154 Gobo 14 shake (from slow to fast)
155 – 159 Gobo 15 shake (from slow to fast)
160 – 207 Positive ow (from fast to slow)
208 – 255 Reverse ow (from slow to fast)
9 Prism 1
000-127 Prism 1 out
128-255 Prism 1 in
10 Prism 1 Rotation
000-127 Prism angle adjustment
128-190 Reverse rotation (from fast to slow)
191-192 Stop
193-255 Forward rotation (from slow to fast)
11 Prism 2
000-127 Prism 2 out
128-255 Prism 2 in
12 Prism 2 Rotation
000-127 Prism angle adjustment
128-190 Reverse rotation (from fast to slow)
191-192 Stop
193-255 Forward rotation (from slow to fast)
13 Focus 000-255 Pattern denition from far to near
14 7-Color Effect
000-127 7-Color Effect out
128-255 7-Color Effect in
15 Frost
000-127 Frost out
128-255 Frost in
16 Reset
000-049 No Function
050-099 Small Motor Reset
100-199 Big Motor (Pan/Tilt) Reset
200-255 All Motor Reset
Extended Channel:
17 Pan/Tilt Speed
000-255 Speed from fast to slow
18 Color Wheel Speed
19 Dimmer-Prism-Frost Speed
20 Gobo Wheel Speed
SPECIAL INSTRUCTIONS
1. During the reset process, press and hold the “OK” button for 5 seconds to interrupt the reset.
2. Press and hold the “OK” button during power-on to interrupt the reset process and enter test
mode.
3. Signal indicator:
• The ERR red indicator ashes to indicate that there is an error message. Go to the "System Infor-
mation" -> System Error" to view the error message.
• If the green DMX indicator light is steadily on, the reception of the DMX signal is OK. If it goes
frequently off, there is no DMX signal.
• The green indicator on the motor drive board ashes quickly at 1 second intervals, indicating
that the serial port signal sent by the display board is received. If it ashes slowly at 2 second
intervals, it means that there is a problem with the motor drive board.
