AGA marvel ML24RF - Installing the Anti Tip Device

9
NOTE
INSTALLING THE ANTI TIP DEVICE
FOR FREESTANDING INSTALLATIONS
When the oor mounted anti-tip bracket is used the mini-
mum adjusted height of the cabinet is increased by
3
⁄8" (9 mm).
Figure 10a
"V" notches
in bracket
"V" notches
in bracket
Figure 10
21
1
⁄2"
(54.6 cm)
Front of cabinet line
Rear Leveling leg
Side of cabinet line
Rear of cabinet line
Screw
