Assembly of burners and adjustment
FITTING BURNER CAP - RAPID AND SEMI -RAPID
BURNERS
PLACE BURNER CAP OVER RETAINING LUGS, THEN TURN
CAP CLOCKWISE TO LOCK INTO POSITION.
BURNER CAP
RETAINING LUGS
Fig. 1.2
ASSEMBLY OF RAPID AND SEMI- RAPID BURNERS
DESN 513513
INJECTOR
ELECTRODE
THERMOCOUPLE
FLAME SPREADER
BURNER CAP
BYPASS
SCREW
Fig. 1.4
Natural Gas Propane
Fig. 1.6
REGULATOR CAP
Fig. 1.3
DESN 513898
WOK BURNER
INJECTOR
Regulator Cap
Fig. 1.5
GAS REGULATOR
DESN 517570
