1.1 Foreword
1.1.1 Service manual
This service manual has been prepared with the latest service information available at publication time.
Read this service manual carefully before performing any service on the machine.
Right-hand and left-hand, as used in manual, are determined by facing the direction machine travels when
in use.
Photos, illustrations and data used in manual were current at time of printing, but due to possible
engineering and/or production changes, each machine can vary. Manufacturer reserves the right to
redesign and change machine as necessary without notification.
WARNING:
Some photographs in the manual show machine with shields removed for a better view
of subject matter. Never operate the machine with any shields removed.
1.1.2 Division and page numbers
Service manual is separated into divisions. Refer to master table of contents.
Each division has an identifying part number with an revision level indicator. Each division has a table of
contents and an index.
Each page is identified with division part number and revision level. Pages are in simple numeric order
within each division.
1.1.3 Unit of measurement
Measurements are given in metric units followed by U.S. equivalent. Hardware sizes are given in
millimetres for metric and inches for U.S. hardware.
1.1.4 Replacement parts
To receive prompt efficient service, always remember to have:
•
Correct part description and part number.
• Model and serial number of machine.
1.1.5 Serial number identification plates
Write the Serial Numbers in the spaces below. Use these numbers when referring to the machine. The
serial number identification plate is located on the left front side of the chassis.
Use these numbers when referring to the machine.
1. General
RoGator 600C 1-3
644410-1
