FENDT 9490 x - EAME 29
D3158100M2 - S/N 502000001 - 502400001
1. General Information
Crop_this_page
3. Hydraulic ram for reel fore/aft
4. Hydraulic ram for reel up/down
5. Main crop elevator
6. Crop elevator chain
7. Elevator chain top shaft
8. Operator cab
9. Steering wheel
10. Operator seat
11. Cylinder access door
12. Unloading auger/tube
13. Rotor Feeder
14. Tank filling auger
15. Grain tank
16. Tank filling elevator
17. Rotor cage
18. Engine
19. Hydrostatic pump (transmission)
20. Rotors
21. Unloading tube
22. Rotor gearbox
23. Straw divider
24. Cutting table
25. Feathering fingers
26. Table Auger
27. Elevator chain front shaft
28. Elevator chain slats
29. Hydraulic table lift ram
30. Threshing cylinder
31. Traction wheels
32. Concave
33. Rear beater
34. Hydrostatic motor (transmission)
35. Main grain pan
36. Fanning mill
37. Bottom fan deflector
38. Top fan deflector
39. Returns thresher
40. Good grain auger
41. Returns auger
42. Top and bottom shaker shoe
43. Top sieve
44. Bottom sieve
45. Sieve extension
46. Rear wheels
47. Chaff spreader
48. Rotor grate
49. Straw chopper
50. Spreader hood/Maxi Spreader
51. Straw hood
1.4.2 Crop Processing
T022859
The crop that is harvested with the combine goes
through five different stages of processing.
1. Feeding
2. Threshing
3. Separation
4. Cleaning
5. Grain Tank and Unloading
These stages are explained in the following sec-
tions.
NOTE: The illustrations are intended as generic ex-
amples of the machine functionality and might
therefore be visually different from the appearance
of the purchased machine.
I052173
Fig. 2.
