DX- D 600
User Manual
0242F EN 20181218
101
Illustration 4-32
Patient Positioning In Double Panel Systems
X-Ray Beam
Collimator Light
Collimator Knobs
Laser Line
Laser Line
X-Ray Beam
Collimator Light
Collimator Knobs
