7.1.3 MANUAL MODE
To be in manual mode, the reasons are:
MESSAGE DESCRIPTION
DETECTOR The selected Workstation (DIRECT) does not allow the automatic mode.
KEY The Collimator back key is turned.
SID The SID is out of the configured range for the automatic collimation.
STATUS The Ceiling Suspension is not on the DR Detector Area or it is moving.
ANG
The Angulation angle of the T ube is ≥3
o
.
ROT The Rotation angle of the Tube is ≥3
o
.
COLROT The Collimator is rotated.
NO -CASSETTE The Grid is out (Just when the Grid is removable).
BUCKYROT The RAD W all Stand Detector is rotated.
CENTER The X-ray Beam is not centered with the DR Detector center.
MODALITY The System is currently on STITCHING Mode.
7.1.4 COLLIMATION LIGHT CONTROL
Collimator Light activates in two different modes.
MANUALLY. Press on the MANUAL CONTROL Button.
AUTOMATICALLY. The collimator is controlled by the Ceiling
Suspension. The light will switch on when:
G Collimator Blades change their configuration.
G Collimator is rotated.
G DIRECT Workstation is selected and any brake of the Ceiling
Suspension is released, or any of the Console Controls are pressed.
G RAD TABLE Workstation is selected and any of the RAD Table or
DR Detector brakes are released.
G RAD WALL STAND DR Workstation is selected and the vertical
or tilting brakes are released.
G The Ceiling Suspension is moving in manual mode and is in the
SID area.
G Just after finishing the Auto-Center and Auto-tracking
movements.
