AGFA DX-D 600 - X-Ray Tube Specifications; Collimator Specifications

DX- D 600
User Manual
0242F EN 20181218
178
11.4 X-RAY TUBES
CANON E7884X
Low Speed -- Rotating Anode, Focal Spots: 0.6 mm / 1.2 mm
Anode kHU / kVp: 300 kHU / 150 kVp, Target Angle: 12°
Maximum Specified Energy Input in 1 hour: 150 kVp @ 3408 mAs
Inherent Filtration of X-ray Source (Tube + Collimator): refer to Identification Label
CANON E7252X
High Speed -- Rotating Anode, Focal Spots: 0.6 mm / 1.2 mm
Anode kHU / kVp: 300 kHU / 150 kVp, Target Angle: 12°
Maximum Specified Energy Input in 1 hour: 150 kVp @ 5760 mAs
Inherent Filtration of X-ray Source (Tube + Collimator): refer to Identification Label
CANON E7254FX
High Speed -- Rotating Anode, Focal Spots: 0.6 mm / 1.2 mm
Anode kHU / kVp: 400 kHU / 150 kVp, Target Angle: 12°
Maximum Specified Energy Input in 1 hour: 150 kVp @ 4800 mAs
Inherent Filtration of X-ray Source (Tube + Collimator): refer to Identification Label
CANON E7869XX
High Speed -- Rotating Anode, Focal Spots: 0.6 mm / 1.2 mm
Anode kHU / kVp: 600 kHU / 150 kVp, Target Angle: 12°
Maximum Specified Energy Input in 1 hour: 150 kVp @ 5189 mAs
Inherent Filtration of X-ray Source (Tube + Collimator): refer to Identification Label
11.5 COLLIMATORS
Model R225 / R225 DHHS MANUAL R225 ACS AUTOMATIC
Shape Rectangular Rectangular
Field
Maximum field
430 x 430 mm SID 1 10 cm
(¦1% SID)
430 x 430 mm SID 90 cm
(¦1% SID)
Minimum field 00 x 00 mm (¦1% SID) 00 x 00 mm (¦1% SID)
Ave rage illumination > 160 lx > 160 lx
Edge contrast ratio >4:1 >4:1
L
i
h
t
f
i
l
d
Accuracy <2%SID <2%SID
Light fie ld
Display of center Cross lines Cross lines
Inherent filtration Min. 2.0 mmAl. Min. 2.0 mmAl.
Type of lamp White LED White LED
Drive of leaves Manual Automatic
External dimension (W x D x H ) 244 x 282 x 216 244 x 282 x 216
