GUIDANCE AND MANUFACTURER’S DECLARATION - ELECTROMAGNETIC IMMUNITY
(IEC 60601-1-2:2007)
The DX-D 600 Radiographic Room is intended for use in the electromagnetic environment specified below.
The customer or Operator of the DX-D 600 Radiographic Room should assure that it is used in such an environment.
Immunity Test
IEC 60601- 1-2:2007
Test Level
Compliance Level
Electromagnetic
Environment - Guidance
Electrostatic discharge (ESD)
IEC 61000-4-2
¦ 6 kV contact
¦ 8kVair
¦ 6 kV contact
¦ 8kVAir
Floors should be wood, concrete or
ceramic tile.
If floors are covered with synthetic
material, the relative humidity
should be
at least 30 %.
Electrical fast transient/burst
IEC 61000-4-4
¦ 2 kV for power supply lines
¦ 1 kV for input/output lines
¦ 2 kV for power supply lines
¦ 1 kV for input/output lines
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
¦ 1 kV line(s) to line(s)
¦ 2 kV line(s) to earth
¦ 1 kV symmetrical coupling
¦ 2 kV asymmetrical coupling
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage dips, short interruptions
and voltage variations on power
supply input lines.
IEC 61000-4-11
<5 % UT
( >95 % dip in UT)
for 0.5 cycles
40 % UT
(60%dipinUT)
for 5 cycles
70 % UT
(30%dipinUT)
for 25 cycles
<5 % UT
(>95 % dip in UT)
for 5 s
>95 %
for 0.5 periods
60 %
for 5 periods
30 %
for 25 periods
>95 %
for 250 periods
Mains power quality should be that
of a typical commercial or hospital
environment. If the user of the
DX-D 600 Radiographic Room
requires continued operation during
power mains interruptions, it is
recommended that the DX-D 600
Radiographic Room is powered
from an Uninterruptible Power
Supply or a battery.
Power frequency (50/60 Hz)
magnetic field
IEC 61000-4-8
3A/m 3A/m
Power frequency magnetic fields
should be at levels characteristic of
a typical location in a typical
commercial or hospital
environment.
NOTE - U
T
is the a.c. mains voltage prior to application of the test level.
