AGFA DX-G - The User Interface

50
2321 E EN 20130722
DX-G/DX-M
The User Interface
The digitizer has two operation modes:
• the operator mode for basic operation,
• the service mode reserved for trained service personnel.
The functions of the operator mode are described in this manual.
The digitizer interfaces with the user via:
• a touch panel which enables access to all functions,
• a status indicator.
Figure 2: User interface
1. Status indicator.
2. Touch panel.
3. On/Off switch (main switch).
4. Ethernet connection (located at the rear side).
