16
1159A 1GHz Active Differential Probe
Recommended Probe Configurations
Wire Leads
You may use wire leads with any of the tip adapters.
Grabbers
Using grabbers and wire leads results in significant lead length. Expect
measurement quality degradation with fast signals.
Connect Leads
to Test Points
Ground
Opt
0.5 mm or 0.8 mm Grabbers
Ground
Opt
