7
1159A 1GHz Active Differential Probe
Attaching External Attenuators to the Probe
Other Probe Accessories
The Agilent Wedge was designed to interface directly with the differential probe.
These devices simplify connections to surface mount integrated circuits and have
output pins compatible with the probe tip and attenuator sockets.
Attaching External Attenuators to the Probe
The external attenuators plug directly on to the probe tip. They are calibrated
at the factory to provide the optimum common mode rejection and should not
be swapped between probes.
The 1159A probe’s best performance is achieved when the probe attenuation is set
to /10 in the Infiniium’s Probes Setup dialog box.
1159A Attenuator
Div-By-10 1 GHz
Div-By-20 1 GHz
1159A AC Coupler
Always Install Last
