Agilent Technologies 6060B - Secondary Interface S.A. Test No. 3

41
Table 3-10. Secondary Interface S.A. Test No. 3
Descri
p
tion: These si
g
natures check transient
g
enerator IC's U310 throu
g
h U316. The si
g
natures are valid for U301
Signatures:
+5V U311-20 U310-20 U313-20 U312-16 U316-6,7,8 U315-16 U314-14
Common U311-10 U310-10 U313-10 U312-8 U316-4,5,18 U315-8 U314-7
SD(0) U311-3 = UFOA U310-3 = UFOA
SD(1) U311-4 = AP48 U310-4= AP48
SD(2) U311-7 = U93A U310-7 = U93A
SD(3) U311-8 = P070 U310-8 = P070
SD(4) U311-13 = 834A U310-13 = 834A
SD(5) U311-14 = 8A16 U310-14 = 8A16
SD(6) U311-17 = 1UUO U310-17 = 1UUO
SD(7) U311-18 = H083 U310-18 = H083
RCK_LOW U311-11 = UP15
RCK_HI U310-11 = 355F
OE U311-1 = 8986 U316-12 = 8986
OE U310-1 = 51AH U316-11 = 51AH
Q1 U311-2 = 6P1A U310-2 = 6P1A U312-4 = 6P1A
Q2 U311-5 = A989 U310-5 = A989 U312-5 = A989
Q3 U311-6 = 486A U310-6 = 486A U312-6 = 486A
Q4 U311-9 = FH57 U310-9 = FH57 U312-7 = FH57
Q5 U311-12 = U1AC U310-12 = U1AC U312-10 = U1AC
Q6 U311-15 = 8HF6 U310-15 = 8HF6 U312-11 = 8HF6
Q7 U311-16 = CCU8 U310-16 = CCU8 U312-12 = CCU8
Q8 U311-19 = 50P3 U310-19 = 50P3 U312-13 = 50P3
U349-1,5,8,16 U350-1 U351-13 U352-2,4,6,12,14 U353-5,9,11 = 0000 pulsing
U313-2 = FU49 U316-1 = 0CH8
U313-3 = 98H4 U316-2 = 3505
U313-4 = 746A U316-3 = H210
U313-6 = H82C U316-9 = 98H4
U313-7 = H8HH U316-14 = P9H3
U313-9 = 0000 U316-15 = H82C
U313-11 = C1H7
U313-14 = H82C U315-1 = H82C
U313-15 = FU49 U315-5 = H82C
U313-17 = 4OUU U315-9 = OOU6
U313-18 = 0000 U315-10 = H8HH
U313-19 = C1H7 U315-11 = H82C
U315-13 = H82C
U312-2 = H82C
U312-3 = P9H3 U314-1 = 4OUU
U312-9 = H82C U314-2 = H82C
U312-14 = FU49 U314-3 = C1H7
U312-15 = FU49 U314-4 = H82C
U314-10 = H82C
U314-12 = H82C
U314-13 = 4OUU
