Table 1-3. Replaceable Parts List
Description Agilent Part No.
(Unless otherwise specified, parts apply to all models.)
Collar, rotary output control 5040-1700
Foot, cabinet 5041-8801
Fuse, power
Series 654xA, 100 Vac line voltage, 6 AM 2110-0056
Series 654xA, 120 Vac line voltage, 5 AM 2110-0010
Series 654xA, 220/230/240 Vac line voltage, 3 AM 2110-0003
Series 655xA, 100 Vac line voltage, 15 AM 2110-0054
Series 655xA, 120 Vac line voltage, 12 AM 2110-0249
Series 655xA, 220/230/240 Vac line voltage, 7 AM 2110-0614
Series 657xA, 200 Vac line voltage, 25 AM* 2110-0849
Series 657xA, 230 Vac line voltage, 25 AM* 2110-0849
*This is an internal fuse not replaceable by the operator.
Knob, rotary output control 0370-1091
Lockwasher, output bus bar, 1/4 spring (Series 657xA) 3050-1690
Manual, service (Series 654xA and 655xA) 5959-3376
Manual, service (Series 657xA and 667xA) 5961-2583
Nut, output bus bar, hex 1/4-20xl/2 (Series 657xA) 2950-0084
Nut, power ground, hex w/lw 3/8x32 0590-0305
Power cord assembly (Series 657xA) (See “Options”)
Resistor, calibration (See Appendix A)
Safety cover, ac input, w/strain relief connector & rubber boot (Series 657xA) 5040-1676
Safety cover, dc output (Series 654xA/655xA) 0360-2191
Safety cover, dc output (Series 657xA) 5040-1674
Screw, bus bar (Series 655xA) 0515-1085
Screw, carrying strap & safety cover, M5x0.8xl0 mm 0515-1132
Screw, dc output safety cover (Series 654xA,655xA) 0515-1085
Screw, output bus bar, 1/4-20xl/2 (Series 657xA) 2940-0103
Screw, output sense terminal, M3x0.5x8 mm 0515-0104
Terminal, crimp, ac power cord, L or N terminal (Series 657xA) 0362-0681
Terminal, crimp, ac power cord, Gnd terminal (Series 657xA) 0362-0207
To Next Page
