Measure Commands
DEFine
NOTE Using "mV" or "V" following the numeric value for the voltage value will cause Error 138-Suffix not allowed.
Instead, use the convention for the suffix multiplier as described in “Command Syntax” on page 1-23.
Example 10 OUTPUT 707;":MEASURE:DEFINE? THRESHOLDS"
Table 18-2. :MEASure:DEFine Interactions
MEASure Commands THResholds TOPBase EWINdow CGRAde DELTatime TREFerence
RISEtime x x x
FALLtime x x x
PERiod x x
FREQuency x x
VTOP x
VBASe x
VAMPlitude x
PWIDth x x
NWIDth x x
OVERshoot x x
DUTYcycle x x
DELTatime x x
VRMS x x
PREShoot x x
VLOWer x x
VMIDdle x x
VUPPer x x
VAVerage x x
VARea x x
DELTatime x x x
CGRade:CRATio x x
CGRade:CROSsing x x
CGRade:DCDistortion x x x
CGRade:DCYCle x x x
CGRade:ERATio x
CGRade:EHEight x
CGRade:ESN x
CGRade:OFACtor x
CGRade:OLEVel x
CGRade:PWIDth x x
CGRade:ZLEVel x
