18-33
Measure Commands
JITTer:RJSValue
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MEASURE:JITTER:RJSTABILIZE ON”
JITTer:RJSValue
Command :MEASure:JITTer:RJSValue <RJ_set_num>
Sets the RJ stabilization value. Use the MEASure:JITTer:RJSTabilize command to turn RJ sta-
bilization on or off.
Restrictions Jitter mode. Software revision A.04.20 and above (86100C instruments).
Query :MEASure:JITTer:RJSValue?
This query returns the fixed RJ value for RJ stabilization.
Returned Format [:MEASure:JITTer:RJSValue] <RJ_set_num><NL>
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MEASURE:JITTER:RJSVALUE 6E-12”
JITTer:SIGNal
Command :MEASure:JITTer:SIGNal {CLOCk|DATA}
Specifies the type of signal being measured.
Restrictions Jitter mode. Software revision A.04.00 and above (86100C instruments). When writing new
code for software revision A.07.00 and above, use the recommended command “SINTeg-
rity:SIGNal” on page 18-42.
Query :MEASure:JITTer:SIGNal?
This query returns the current setting for the signal type.
Returned Format [:MEASure:JITTer:SIGNal] {CLOCk|DATA}<NL>
Example :MEASURE:JITTER:SIGNAL DATA
JITTer:SIGNal:AUTodetect
Command :MEASure:JITTer:SIGNal:AUTodetect {ON|OFF}
Turns automatic detection of the signal type (clock or data) on or off. The automatic detec-
tion occurs during an autoscale.
Restrictions Jitter mode. Software revision A.04.00 and above (86100C instruments). When writing new
code for software revision A.07.00 and above, use the recommended command “SINTeg-
rity:SIGNal:AUTodetect” on page 18-42.
Query :MEASure:JITTer:SIGNal:AUTodetect?
This query returns the current setting for automatic signal detection.
Returned Format [:MEASure:JITTer:SIGNal:AUTodetect] {ON|OFF}<NL>
Example :MEASURE:JITTER:SIGNAL:AUTODETECT ON
JITTer:TJ?
Query :MEASure:JITTer:TJ?
Returns the total jitter value measured on the current source.
