Agilent Technologies 86100C Programmer's Guide

3-8
Common Commands
*RST (Reset)
Table 3-4. Default Setup (1 of 4)
Acquisition
Run/Stop 100 ms
Grid on
30
Enabled
8 hours
Default legend
Off
Off (until the first marker is placed on
the screen)
User selectable if more than one
source is available.
28 ns
0V
Points/Waveform (Record length) Automatic - 1350 points
Averaging Off
# of Averages 16
Trigger
Source Front Panel
Bandwidth 2.5 GHz
Hysteresis Normal
Slope Positive
Gated Trigger Off
Level 0 V
Time Base
Units Time
Scale 1 ns/div
Position 24 ns
Reference Left
Display
Persistence Variable (oscilloscope mode)
Gray Scale (Infinite) (Eye/Mask mode)
Persistence Time 100 ms
Graticule Grid on
Intensity 30
Backlight Saver Enabled
Turn off backlight after 8 hours
