1-10
Introduction
Files
Table 1-3. Default File Locations
File Type Default Location
Waveform - internal format, text format (Verbose, XY Verbose, or Y
values),
D:\User Files\waveforms
Pattern Waveforms D:\User Files\waveforms
Setup D:\User Files\setups
Color Grade - Gray Scale D:\User Files\colorgrade-grayscale
Jitter Memory D:\User Files\jitter data
Screen Image D:\User Files\screen images
Mask C:\Scope\masks (standard masks)
D:\User Files\masks (user-defined masks)
TDR/TDT calibration data (software revision A.05.00 and below) D:\User Files\TDR normalization
TDR/TDT calibration data (software revision A.06.00 and above) D:\User Files\TDR calibration
MATLAB script D:\User Files\Matlab scripts
S-Parameters D:\User Files\S-parameter data
Table 1-4. File Locations (Loading Files)
File Name Rule
Full path name Use file name and path specified
Relative path name Full path name is formed relative to the present working directory, set with the command :DISK:CDIR. The
present working directory can be read with the query :DISK:PWD?
File name with no
preceding path
Add the file name to the default path (D:\User Files) based on the file type. (C drive on 86100A/B
instruments.)
