Agilent Technologies 86100C Programmer's Guide

9-4
Clock Recovery Commands
CLBandwidth
CLBandwidth
Command
(83496A Option
300)
:CRECovery{1 | 3}:CLBandwidth <bandwidth>
This 83496A Option 300 command sets or queries an 83496A Option 300 module’s loop band-
width. You must issue the LBWMode FIXed command before using the CLBandwidth com-
mand. A settings conflict error is reported if the module’s loop bandwidth mode is set to be
rate dependent (RDEPendent). Refer to “LBWMode” on page 9-6. The loop bandwidth can be
any bandwidth within 30 kHz to 10 MHz specified to 3 significant digits. The default setting is
60 kHz.
Restrictions Software revision A.04.20 and above.
Example 10 OUTPUT 707; ":CRECOVERY1:CLBANDWIDTH 1.7E6"
Query :CRECovery{1 | 3}:CLBandwidth?
Returned Format [:CRECovery{1 | 3}:CLBandwidth] <bandwidth><NL>
Table 9-2. Module Data Rates
Rate
(Mb/s)
83491 83492 83493 83494 83494 Option 103 83494 Option 106 83494 Option 107 83495 83496 83496 Option 200
Trigger on data
••••• • ••• •
155.52
••••• • • • •
622.08
••••• • • • •
1062.50
•• • •
1250.00
••• • •
2125.00
•• • •
2488.32
• •••• • • • •
2500.00
••• • •
2666.06
•• ••
9953.28
•••
10312.50
•••
10664.23
•••
10709,225
•• •
9.953 Gb/s–
11.32 Gb/s
••
Continuous
••
