Clock Recovery Commands
RATE
[:CRECovery{1 | 3}:RATE] {TOData | R155 | R622 | R1062 | R1250 | R2125 | R2488 | R2500 | R2666 | R9953 | R10312
| R10664 | R10709 | RANGE10G | CONTinuous}<NL>
Example 20 OUTPUT 707;":CRECOVERY1:RATE?"
Table 9-4. Valid Data Rate Arguments Versus Modules
Rate
Parameter
Rate (Mb/s)
Module Model Number
a
83491 83492 83493 83494 83494 Option 103 83494 Option 106 83494 Option 107 83495 Option 100 & 200 Option 101 & 200 83496 83496 Option 200
TOData
b
—
••••• • • • • •
R155 155.52
••••• • • • •
R622 622.08
••••• • • • •
R1062 1062.50
•• • •
R1250 1250.00
••• • •
R2125 2125.00
•• • •
R2488 2488.32
• •••• • • ✺✺
R2500 2500.00
••• • •
R2666 2666.06
•• • •
R9953 9953.28
•••
R10312 10312.50
•••
R10664 10664.23
•• •
R10709 10709,225
•• •
RANGE10G 9.953 Gb/s–
11.32 Gb/s
••
CONTinuous
c
—
••
a. The ✺ symbol indicates the default data rate.
b. Trigger on data.
c. The CONTinuous argument is returned in queries and can not be used to set the bandwidth.
