Function Commands

PEELing

NOTE This query returns the current offset value of the specified function only when the respective function display is

ON.

Returned Format [:FUNCtion<N>:OFFSet] <offset_value><NL>

Example 20 OUTPUT 707;":FUNCTION2:DISPLAY ON"

30 OUTPUT 707;":FUNCTION2:OFFSET?"

PEELing

Command :FUNCtion<N>:PEELing <operand>

Defines a function that applies TDR peeling to source 1 and places the result in the selected

function waveform. The TDR peeling is provided with Option 202, Enhanced Impedance and

S-Parameter software, and is used in TDR mode to analyze reflected signals at the source

and deconvolve the time domain reflections to create an impedance profile of the device

being tested. For differential and common mode responses, apply the TDR peeling to the dif-

ferential or common-mode response trace. TDR peeling can not be applied to TDT responses.

TDR Peeling is only available in TDR/TDT Mode.

Restrictions Available only in TDR/TDT mode. Software revision A.06.00 and above (86100C instru-

ments).

<operand> {CHANnel<N> | FUNCtion<N> | RESPonse<N> | WMEMory<N>}

Example 10 OUTPUT 707;":FUNCTION1:PEELING CHANNEL1,WMEMORY1"

RANGe

Command :FUNCtion<N>:RANGe <full_scale_range>

This command defines the full scale vertical axis of the selected function. This automatically

changes the mode from auto to manual. <full_scale_range> is the full-scale vertical range.

Example This example sets the full scale range for function 1 to 400 mV.

10 OUTPUT 707;":FUNCTION1:RANGE 400E-3"

Query :FUNCtion<N>:RANGe?

This query returns the current full scale range setting of the specified function only when the

respective function display is ON.

Returned Format [:FUNCtion<N>:RANGe] <full_scale_range><NL>

Example 20 OUTPUT 707;":FUNCTION2:DISPLAY ON"

30 OUTPUT 707;":FUNCTION2:RANGE?"

SUBTract

Command :FUNCtion<N>:SUBTract <operand>,<operand>

This command defines a function that algebraically subtracts the second operand from the

first operand.

<operand> {CHANnel<N> | FUNCtion<N> | RESPonse<N> | WMEMory<N> | <float_value>}

Example This example defines a function that subtracts waveform memory 1 from channel 1.
