Agilent Technologies 86100C Programmer's Guide

18-18
Measure Commands
CGRade:PEAK?
<value> is the logic one level. If SENDvalid is ON, the <result_state> is returned with the
measurement result. Refer to Table 18-4 on page 18-39 for a list of the result states.
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MEASURE:CGRADE:OLEVEL?”
CGRade:PEAK?
Query :MEASure:CGRade:PEAK? [<source>]
Returns the maximum number of hits of the color grade display. The data for color grade dis-
play is the same as for gray scale display. If the source is not set, the lowest numbered signal
display that is on will be the source of the measurement. <source> is {CHANnel<N> | FUNC-
tion<N> | CGMemory}.
Mode Eye or Oscilloscope modes.
Returned Format [:MEASure:CGRade:PEAK] <value>[,<result_state>]<NL>
<value> is the number of hits. If SENDvalid is ON, the <result_state> is returned with the
measurement result. Refer to Table 18-4 on page 18-39 for a list of the result states.
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MEASURE:CGRADE:PEAK?”
CGRade:PWIDth
Command :MEASure:CGRade:PWIDth [<source>]
Measures the pulse width of the eye diagram on the color graded display. If the source is not
set, the lowest numbered signal display that is on will be the source of the measurement.
<source> is {CHANnel<N> | FUNCtion<N> | CGMemory}.
Mode Eye mode only. Ensure that the eye type is set to RZ. See “DEFine” on page 18-19.
Query :MEASure:CGRade:PWIDth? [<source>]
This query returns the pulse width of the color graded display.
Returned Format [:MEASure:CGRade:PWIDth] <value>[,<result_state>]<NL>
<value> is the pulse width. If SENDvalid is ON, the <result_state> is returned with the mea-
surement result. Refer to Table 18-4 on page 18-39 for a list of the result states.
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MEASure:CGRade:PWIDth?”
CGRade:SOURce
Command :MEASure:CGRade:SOURce <source>
Sets the default source for color grade-gray scale measurements. If this source is not set, the
lowest numbered color grade-gray scale signal that is on will be the source of the measure-
ments. This command is similar to the :MEASure:SOURce command, with the exception of
specifying a color grade-gray scale signal. <source> is {CHANnel<N> | FUNCtion<N> |
CGMemory}. <N> is an integer, from 1 through 4.
Mode Eye and Oscilloscope modes.
Query :MEASure:SOURce?
