Agilent Technologies 86100C Programmer's Guide

26-4
Waveform Memory Commands
YRANge
Query :WMEMory<N>:YOFFset?
The query returns the current y-axis (vertical) offset for the selected waveform memory.
Returned Format [:WMEMory<N>:YOFFset] <offset_value><NL>
Example This example sets the y-axis (vertical) offset of waveform memory 2 to 0.2V.
10 OUTPUT 707;":WMEMORY2:YOFFSET 0.2"
YRANge
Command :WMEMory<N>:YRANge <range_value>
This command sets the y-axis, vertical range for the selected memory. The vertical scale is
the vertical range divided by 8. <N> is the memory number is an integer from 1 to 4.
<range_value> is the vertical range value.
Query :WMEMory<N>:YRANge?
The query returns the Y-axis, vertical range for the selected memory.
Returned Format [:WMEMory<N>:YRANge] <range_value><NL>
Example This example sets the y-axis (vertical) range of waveform memory 3 to 0.2 volts.
10 OUTPUT 707;":WMEMORY3:YRANGE 0.2"
