A-8 AppendixA
Preset Conditions
Preset State
Table A-4 Calibration Conditions
Preset Conditions Preset Value
Correction Off
Calibration Type None
Calibration Kit: (8719/20)
8719ET/ES and 8720ET/ES 3.5-mm
8722ET/ES 2.4-mm
8753ES 7-mm
type-N, 75 Ω (8753ET/ES Option 075)
8753ET type-N, 50 Ω
Enhanced Reflection Calibration Off
System Z0 50 Ω
75 Ω (8753ET/ES Option 075)
Velocity Factor 1
Extensions On/Off Off
Extensions Setting:
Port 1 0 s
Port 2 0 s
Input A 0 s
Input B 0 s
Chop A and B (ES models only) On
Chop RFL & TRN (ET models only) On
Power Meter Calibration: Off
Number of Readings 1
Power Loss Correction Off
Sensor A/B A
Interpolated Error Correction
On
1
1. Can be changed by pressing
.
System
To Next Page
