Appendix A A-9
Preset Conditions
Preset State
Table A-5 Electronic Calibration (ECal) Conditions
Preset Conditions Preset Value
Module A (information may not be loaded)
Omit Isolation On
Isolation Averages 10
Manual Thru Off
Table A-6 Marker Conditions
Preset Conditions Preset Value
Markers On/Off All Markers Off
Marker Setting (all markers) 1 GHz
Last Active Marker 1
Reference Marker None
Marker Mode Continuous
Display Markers On
Delta Marker Mode Off
Coupling On
Marker Search Off
Marker Target Value −3 dB
Marker Width On/Off Off
Marker Width Value −3 dB
Marker Tracking Off
Marker Stimulus Offset 0 Hz
Marker Value Offset 0 dB
Marker Aux Offset (Phase) 0 Degrees
Marker Statistics Off
Polar Marker Lin Mkr
Smith Marker R+jX Mkr
