Agilent Technologies DSO3062A User Manual

Service
Performance Test Record
4-21
Performance Test Record
DC Gain Test
Vertical
Sensitivity
Power
Supply
Setting
V
DMM+
V
DMM-
V
Scope+
V
Scope-
Calculated
DC Gain
Offset Gain
Test Limits
Channel 1
2 mV/div ±6 mV +0.96 to +1.04
5 mV/div ±15 mV +0.96 to +1.04
10 mV/div ±30 mV +0.97 to +1.03
20 mV/div ±60 mV +0.97 to +1.03
50 mV/div ±150 mV +0.97 to +1.03
100 mV/div ±300 mV +0.97 to +1.03
200 mV/div ±600 mV +0.97 to +1.03
500 mV/div ±1.5 V +0.97 to +1.03
1 V/div ±2.4 V +0.97 to +1.03
2 V/div ±6.0 V +0.97 to +1.03
5 V/div ±15.0 V +0.97 to +1.03
Channel 2
2 mV/div ±6 mV +0.96 to +1.04
5 mV/div ±15 mV +0.96 to +1.04
10 mV/div ±30 mV +0.97 to +1.03
20 mV/div ±60 mV +0.97 to +1.03
50 mV/div ±150 mV +0.97 to +1.03
100 mV/div ±300 mV +0.97 to +1.03
200 mV/div ±600 mV +0.97 to +1.03
500 mV/div ±1.5 V +0.97 to +1.03
1 V/div ±2.4 V +0.97 to +1.03
2 V/div ±6.0 V +0.97 to +1.03
5 V/div ±15.0 V +0.97 to +1.03
