Hardkey and Softkey Reference ESG Family Signal Generators

Save

4-92 User’s Guide

Clear Text

Press this softkey to delete the comment text in the active entry area. If

you want to change the comment text saved with a register, use this

softkey to quickly delete the existing text, then use the remaining

editing features to enter a new comment.

Softkey Location:

Save > Add Comment To Seq[n] Reg[nn] > Editing Keys >

Clear Text

Delete All Regs in Seq [n]

Press this softkey to delete the data saved in all of the registers of the

selected sequence. Do not press this softkey until you have selected the

correct sequence using the

Select Seq softkey. For example, if you want to

delete all of the registers that are saved in sequence 4, press

Select Seq.

The currently selected sequence is displayed in the active entry area.

Change the number to 4 using the up and down arrow keys, the front

panel knob, or enter a 4 using the numeric keypad and press the

Enter

terminator softkey. Sequence 4 is now displayed in all softkeys which

specify a sequence in this menu. Now press

Delete All Regs in Seq [4] and

the data in all of the registers stored in sequence 4 will be deleted. Be

certain that you want to delete the data; you cannot recover it once

deleted.

NOTE This softkey has exactly the same function as the softkey with the

identical name in the front panel Recall key menu.

Softkey Location:

Save > Delete All Regs in Seq [n]

Delete All Sequences

Press this softkey to delete all of the data in all saved registers of all

sequences. Be certain that you want to delete the data; you cannot

recover it once deleted.

NOTE This softkey has exactly the same function as the softkey with the

identical name in the front panel Recall key menu.

Softkey Location:

Save > Delete All Sequences
