ESG Family Signal Generators Hardkey and Softkey Reference
Utility
User’s Guide 4-137
Seq
Press this softkey to set the current catalog type to Seq and display the
catalog of sequence files.
Softkey Location:
Utility > Memory Catalog > Catalog Type >
ARB Catalog Types > Seq
Shape
Press this softkey to set the current catalog type to Shape and display
the catalog of shape files.
Softkey Location:
Utility > Memory Catalog > Catalog Type > Shape
Software Options
This softkey accesses a menu where you can configure your signal
generator to enable any software option that you have purchased.
Software options are linked to specific optional hardware that must
first be installed before the software option can be operational. Adding
new software options requires the use of a license key that is provided
by Agilent Technologies at the time of purchase.
NOTE If a previously installed software option is disabled, verify that the
optional hardware is installed, the hardware option is enabled, and the
software option is enabled with the correct license key. Refer to your
License Key Certificate for the correct license key or, if the option was
installed by Agilent Technologies, contact your local service office and
tell them the instrument’s model number, the host ID number, and the
software option that should be enabled.
CAUTION Don’t modify the license key for enabled software options. You will
disable the option.
Refer to Chapter 2, “Using Functions,” for an example of enabling
software options.
Softkey Location:
Utility > Instrument Adjustments > Software Options
State
Press this softkey to set the current catalog type to State and display
the catalog of state files.
Softkey Location:
Utility > Memory Catalog > Catalog Type > State
