Installation Note E4400-90214 3
Standard ESG-D to Option UND Upgrade Kit
Introduction
This installation note contains instructions for installing Option UND, the dual arbitrary waveform
generator, in a standard ESG-D or ESG-DP signal generator. This note applies to two kits. The kit used
is determined by the options installed. The kits are identified and described below.
Perform this installation in its entirety and in the order presented.
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . ESG-D and ESG-DP Series Signal Generators
Models Affected: . . . . . . . . . . . . . . . . . . . . . . . . . . . E4430B, E4431B, E4432B, E4433B, E4434B,
E4435B, E4436B and E4437B
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . . All
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X) Agilent Service Center
(X) Personnel Qualified by Agilent Technologies
(X) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . . 1.5 hours
Estimated Verification Time: . . . . . . . . . . . . . . . . . 0.5 hour
Kit Part Number Description
E4400-60166 Installs Option UND in signal generators
without Options UN3/4 or UN8/9 installed.
E4400-60181 Installs Options UND in signal generators
equipped with Option UN3/4 or UN8/9.
