4 Installation Note E4400-90167
Installation Kit Parts List
Table 1 Option UN8 Upgrade Kit E4400-60160 Contents
Tools Required
❏ T-10 TORX screwdriver
❏ T-15 TORX screwdriver
❏ Long-nose pliers
❏ 9/16-in. Socket
WARNING Before you disassemble the signal generator, turn the power switch off,
and disconnect the line cord. Failure to unplug the instrument can result
in personal injury.
CAUTION Electrostatic discharge (ESD) can damage or destroy electronic components. All
work on electronic assemblies should be performed at a static-safe workstation.
Item
Quantity Description Part Number
Std
No
Opt’s
*
* Implies no other digital hardware options are installed.
U8
to
UN7
U8
to
UND
1
1 1 1 Board Assembly, Real-Time I/Q Baseband Generator (A7) E4400-60070
2
1 1 1 Board Assembly, Generator/1 Meg (A8) E4400-60154
3
1 0 0 Firmware Upgrade Kit, Digital E4400-60230
4
1 1 1 UN8 Option Label 7120-1232
5
1 1 1 Ribbon Cable Interconnect (W19) 8120-8349
6
1 1 1 Ribbon Cable (W18) 8120-8457
7
2 0 0 SMB Cable (W25/W26) 8120-8748
8
3 0 0 Coax Cable (W3/W4/W5) Longer cables, if needed 8120-5063
9
1 0 0 Installation Note E4400-90167
10
1 1 1 Ribbon Cable (W27), A7 to A8 8120-8725
11
1 0 1 Coax Cable (W24), A7 (Option UN8) to A5 (Option UND) E4400-20131
12
1 0 0 ESG Digital Documentation Set E4400-90322
